Counter Pressure Bottle Filler

Counter Pressure Bottle Filler

Semi-automatic beer bottling-capping machine with control panel Based on the Germany technology and the characteristics of beer production industry, this bottling machine is designed as a small-size beer filling machine for most micro breweries. This machine is of good functions, such as stable...
Chat Now

Product Details

Semi-automatic isobaric/pressurized filling beer bottling-capping machine with control panel(not simple&manual beer bottle filler)


Based on the Germany technology and the characteristics of beer production industry, this bottling machine is designed as a small-size beer filling machine for most micro breweries. This machine is of good functions, such as stable operating, full and well rinsing, filling, capping and sterilizing, etc. It has the main parts as follows: automatic electronic control filling valve, vacuum, preparation of pressure(CO2), photoelectric liquid level detection, automatic filling process, CIP cleaning connector, quick-worn parts, hand sliding door, etc.

There are two main parts of this machine: bottle filler and capper.

Filling part: 2 nozzles

The filling part has 2 heads. You can fill beer into bottles with the 2 heads at same time after operate on the control panel.

2-1_.jpgWorking procedure

(1)Filling procedure: Cylinder raises the bottle base and compact the bottle → Vacuumizing→CO2 pressure preparation→ Filling(CO2 return)→ Valve close → Pressure relief and air discharge → Cylinder lower the bottle base.

Capping part: 1 head

The capping machine is made up of cap holder, capping slideway, capping upper part, capping lower part, elevating part and anti-circling column.


Technology data

Filling heads 2
Capping heads 1
Capacity 100-300BPH
Dimensions 1350×600×2000(mm, L*W*H)
N.W. 200kg
Working voltage(AC) Customized according to the local power supply of the user
Control voltage (DC) 24V
Bottle type

Height: 150~300mm,bottleneck:φ50-φ85mm

Consumption of sterile air 0.2m3/min(0.4~0.6Mpa)
CO2 consumption 260g/100L
Power

Hopper motor: 0.18kw

Motor of vacuum pump: 0.37kw

Motor of rinsing pump: 0.37kw
Capacity of vacuum pump 0. 2m3/h

If you are interested in this bottle filler, feel free to contact Marie via marie@shandonghg.com

Hot Tags: counter pressure bottle filler, China, suppliers, manufacturers, factory, for sale, price
It has a filling speed of 100-300BPH for 330ml-1000ml glass bottles with crown caps.
